LSHF Marker Tube

LSHF HEAT SHRINKABLE MARKING TUBE

Category: Marking System

Operating Temperature	:	-45 ^oC ~ +125^oC
Tensile Strength	:	10.4MPa
Ultimate Elongation	:	200%
Flammability	:	VW-1, LSHF
Dielectric Strength	:	> 15kV/mm
Volume Resistance	:	10¹⁴ Ώ.cm
Copper Stability	:	158^oC , 168 hrs
Colours	:	WHITE

Description

Item No.				Ø			As Supplied (mm)									After Recovered (mm)									Packing Unit
							Inside Diameter					Wall Thickness				Inside Diameter					Wall Thickness
HST-2.5W				2.5			2.50					0.25				1.30					0.38				200 mtr
HST-3.0W				3.0			3.50					0.25				1.50					0.40				200 mtr
HST-4.5W				4.5			5.00					0.25				2.30					0.50				200 mtr
HST-6.0W				6.0			6.50					0.25				3.00					0.55				100 mtr
HST-7.0W				7.0			7.50					0.25				3.50					0.55				100 mtr
HST-8.0W				8.0			8.60					0.30				4.00					0.60				100 mtr
HST-10.0W				10.0			10.60					0.30				5.00					0.60				100 mtr
