VINYL WIRE END CAP

Category:

Material : Soft PVC
Maximum Service Temperature : 80°c
For the insulation works of wire end terminal
Performing the work with a simple one touch to tighten and seal
Standard color : Red, Yellow, Blue, Black, Green ,White, Grey and Brown

ENQUIRE NOW

Item No. Applicable Wire Dimension (mm) Packing Unit
d1 d2 L t
V-1.25 1.5 mm² 3.3 3.1 15.0 0.6 100 pcs
V-2 2.5 mm² 4.5 3.7 16.0 0.7 100 pcs
V-3.5 4.0 mm² 5.7 4.1 18.0 0.8 100 pcs
V-5.5 6.0 mm² 5.7 5.2 20.0 0.8 100 pcs
V-8 10.0 mm² 7.2 6.2 21.0 1.0 100 pcs
V-14 16.0 mm² 10.0 8.0 28.0 1.1 100 pcs
V-22 25.0/35.0 mm² 12.0 9.5 29.0 1.2 100 pcs
V-38 50.0 mm² 14.0 11.8 34.0 1.4 100 pcs
V-60 70.0 mm² 17.0 13.9 42.0 1.5 100 pcs
V-80 95.0 mm² 19.0 16.0 46.0 1.5 50 pcs
V-100 120.0 mm² 22.0 18.0 55.0 1.7 50 pcs
V-125 150.0 mm² 24.0 20.0 60.0 1.8 50 pcs
V-150 185.0 mm² 26.0 22.0 65.0 1.8 50 pcs
V-200 240.0 mm² 32.2 24.0 69.0 2.0 50 pcs
V-250 300.0 mm² 36.5 27.2 75.0 2.0 50 pcs
V-325 400.0 mm² 37.5 30.0 75.0 2.0 25 pcs
V-400 400.0 mm² 45.1 37.5 83.0 2.0 25 pcs
V-500 500.0 mm² 48.2 40.2 85.0 2.0 25 pcs
V-630 630.0 mm² 53.8 45.2 93.0 2.0 25 pcs
